The DALY Smart Active Balance BMS 8S–24S 80A is an intelligent Battery Management System (BMS) designed for medium- to high-voltage lithium battery packs. It supports 8 to 24 cells/cell groups connected in series and provides battery protection, monitoring, cell balancing, temperature management, and smart communication.

Main Specifications

Specification	Details
Brand	DALY
Type	Smart Active Balance BMS
Series support	8S–24S
Maximum continuous current	80A
Balance type	Active balancing
Balance current	Up to approximately 1A, depending on version
Battery chemistry	Li-ion / NMC, LiFePO₄, or LTO depending on model
Bluetooth	Supported on smart versions
Communication	UART / RS485 / CAN depending on version
Temperature sensing	NTC
Protection	Overcharge, over-discharge, over-current, short circuit and temperature
SOC monitoring	Supported
Application	Lithium battery packs, solar storage, EVs, UPS, robotics and energy-storage systems

8S–24S Battery Compatibility

The BMS can be configured for different numbers of series-connected cells:

8S
10S
12S
13S
14S
16S
20S
24S
The DALY Smart Active Balance BMS 8S–24S 80A is an intelligent Battery Management System (BMS) designed for medium- to high-voltage lithium battery packs. It supports 8 to 24 cells/cell groups connected in series and provides battery protection, monitoring, cell balancing, temperature management, and smart communication.
Protection Functions
The 80A BMS provides several important protection functions:
1. Overcharge protection
Prevents individual cells from being charged beyond their safe voltage.
2. Over-discharge protection
Disconnects the battery when cell voltage becomes dangerously low.
3. Over-current protection
Protects the battery and BMS when charging or discharge current exceeds the configured limit.
4. Short-circuit protection
Rapidly disconnects the battery during a short circuit condition.
5. Temperature protection
Uses NTC sensors to monitor battery temperature and protect against abnormal temperature conditions.
Typical Applications
The DALY 8S–24S 80A Smart Active Balance BMS is suitable for:

Li-ion battery packs

LiFePO₄ energy-storage batteries

Solar energy storage systems

High-voltage DIY battery packs

Electric motorcycles and scooters

Electric vehicles

Robotics

UPS systems

Home energy-storage systems

Industrial battery systems

Portable/high-capacity power stations
